Home pageDouble inflatable packer TPD 43 Flex for borehole-Ø 43-67 mm

Double inflatable packer TPD 43 Flex
for borehole-Ø 43-67 mm

for borehole-Ø 43-67 mm, 2 x 290 mm inflation hose, material openings lateral 3 x Ø 9 mm, connecting thread material hose inside G1/2", connecting thread extension line inside M7x1, flexible distance area
Doppel-Blähpacker TPD 43 Flex,
Double inflatable packer TPD 43 Flex, 330 mm injection area
Item No.:
69454
PU:
1 piece
Doppel-Blähpacker TPD 43 Flex
Double inflatable packer TPD 43 Flex, 470 mm injection area
Item No.:
69454
PU:
1 piece
Doppel-Blähpacker TPD 43 Flex,
Double inflatable packer TPD 43 Flex, 530 mm injection area
Item No.:
69454
PU:
1 piece
Doppel-Blähpacker TPD 43 Flex,
Double inflatable packer TPD 43 Flex 980 mm injection area
Item No.:
69454
PU:
1 piece
Vantaggio/Nota
  • Injection area freely selectable, different lengths available
  • Safe application due to screw connections
  • Reusable
  • Safe sealing
  • Variable tension force
  • Hardened sealing surface
  • All parts exchangeable
Materiale in ingresso
  • acrylate gel
  • micro cement
  • 1C injection resin
  • silicate resin
  • polyurethane
  • aqueous solution
  • 2C injection resin
  • injection mortar
  • cement paste
  • cement suspension
  • insulating material
  • water
  • 2C polyurethane
Dati tecnici
Type TPD 43 Flex
Borehole-Ø min.-max. 43-67 mm
Borehole Ø 45 mm max. expansion pressure 140 bar, max. injection pressure 120 bar
Borehole Ø 55 mm max. expansion pressure 60 bar, max. injection pressure 40 bar
Borehole Ø 66 mm max. expansion pressure 50 bar, max. injection pressure 30 bar
Inflation hose length 2 x 290 mm
Material openings lateral 3 x Ø 9 mm
Connection thread for material hose inside G1/2"
Connection thread for expansion line inside M7x1
Securing cord no
Injection area Distance area + 2 x swage fitting
Information
Expansion connections
with union nuts on both sides and cutting ring are available in different lengths.
Please ask us!
