Home pageDouble inflatable packer TPD 57 Flex for borehole-Ø 57-87 mm

Double inflatable packer TPD 57 Flex
for borehole-Ø 57-87 mm

for borehole-Ø 57-87 mm, 2 x 450 mm inflation hose, material openings lateral 3 x Ø 10 mm, connecting thread material hose inside G1/2", connecting thread extension line inside M8x1, flexible distance area
Doppel-Blähpacker TPD 57 Flex,
Double inflatable packer TPD 57 Flex, 330 mm injection area
Item No.:
69456
PU:
1 piece
Doppel-Blähpacker TPD 57 Flex,
Double inflatable packer TPD 57 Flex, 500 mm injection area
Item No.:
69456
PU:
1 piece
Doppel-Blähpacker TPD 57 Flex,
Double inflatable packer TPD 57 Flex, 580 mm injection area
Item No.:
69456
PU:
1 piece
Doppel-Blähpacker TPD 57 Flex,
Double inflatable packer TPD 57 Flex, 750 mm injection area
Item No.:
69456
PU:
1 piece
Doppel-Blähpacker TPD 57 Flex,
Double inflatable packer TPD 57 Flex, 1.000 mm injection area
Item No.:
69456
PU:
1 piece
Vantaggio/Nota
  • Injection area freely selectable, different lengths available
  • Safe application due to screw connections
  • Reusable
  • Safe sealing
  • Hardened sealing surface
  • All parts exchangeable
Materiale in ingresso
  • acrylate gel
  • micro cement
  • 1C injection resin
  • silicate resin
  • polyurethane
  • aqueous solution
  • 2C injection resin
  • injection mortar
  • cement paste
  • cement suspension
  • insulating material
  • injection mortar ¹ ² ³
  • cement paste ¹ ² ³
  • cement suspension ¹ ² ³
  • water
  • 2C polyurethane
Dati tecnici
Type TPD 57 Flex
Borehole Ø min.-max. 57-87 mm
Borehole Ø 60 mm max. expansion pressure 180 bar, max. injection pressure 160 bar
Borehole Ø 70 mm max. expansion pressure 110 bar, max. injection pressure 90 bar
Borehole Ø 84,5 mm max. expansion pressure 90 bar, max. injection pressure 70 bar
Inflation hose length 2 x 450 mm
Material openings lateral 3 x Ø 10 mm
Connection thread for material hose inside G1/2"
Connection thread for expansion line inside M8x1
Securing cord M8
Injection area Distance range + 2 x swage fitting
Information
Expansion connections
with union nuts on both sides and cutting ring are available in different lengths.
Please ask us!
